Inter-Tech 88881152 Datasheet download pdf (Page 2)

Specifications

Motherboard

ATX, µATX

Drive Bays

5.25" external: 2

3.5" external: 1

3.5" internal: 7/4¹

2.5" internal: 0/1¹

Front Connectors

USB 2.0: 1

USB 3.0: 1

Microphone: 1

Headphone: 1

Cooling System

Front: 1x 120mm

Rear: 1x 80 or 120mm

Side: 2x 80, 92 or 120mm

Packing Units

Shipping Unit: 1 Piece

Pallet: 24 Pieces

Guarantee and Warranty

Case 24 Months Warranty

Article Number

EAN-Code

88881152

4260133122680

Scope of Delivery

Screw Set

Speaker

Cable Ties

Features

Blue illuminated Power button

Reset button

Side Panels attached with Thumbscrews

Dustfilter in the base, top and front

USB 3.0, USB 2.0 and audio connectors as

block connector

HD-Audio

¹In use of one 2.5" hard drive, you will lose three 3.5" internal hard drives

Dimensions and Weight

Cage

Case

Package

Height

412mm

428mm

507mm

Width

185mm

200mm

252mm

Depth

400mm

440mm

470mm

Weight (net): 3.6Kg

Weight (gross): 4.42Kg

Certification:

Errors excepted. No warranty for the correctness of the information Stand: 13.11.2013

Power Supply

Connector

Quantity

Max. Length

Mainboard 20+4Pin

P4 12V 4Pin

P4/EPS 4+4Pin

P8 12V 8Pin

PCI-Express 6+2Pin

PCI-Express 6Pin

IDE 4Pin

S-ATA

Floppy

RPM sensor cable

Fan Control

Fan: 120mm

1 2

Certification: 2
