Inter-Tech 88881174 Datasheet download pdf (Page 2)

Errors excepted. No warranty for the correctness of the information State: 05.06.2013

Specifications

Motherboard

µATX*, ITX

Drive Bays

Slot-In: 1

3.5" internal: 1/0¹/2²

2.5" internal: 1/3¹/0²

Front Connectors

USB 3.0: 1

USB 2.0: 1

Microphone: 1

Headühone: 1

External Connectors

SATA data port: 1

4Pin Molex power connector: 1

Cooling System

3x 60x60x10mm

(Rear, as option)

Packing Units

Shipping Unit: 1 Piece

Packing Unit: 7 Pieces

Guarantee and Warranty

Case 24 Months Warranty

Article Number

EAN-Code

88881174

4260133125223

Scope of Delivery

Cable ties

Screw set

2x dust filter

Features

ATX PSU mounting possible

2 full-size PCI cards possible

Side panels and bottom part detachable

4.5mm thick aluminum case

Rubber feet

USB 3.0, USB 2.0 and HD-Audio as block connector

*Micro-ATX Mainboards only up to 190mm depth possible

¹in use of 3x 2.5" HDD, you will lose the possibility to mount two 3.5"HDDs

² in use of 2x 3.5" HDD, you will lose the possibility to mount three 2.5" HDDs

Dimensions and Weight

Cage

Case

Package

Height

266mm

275mm

300mm

Width

213mm

222mm

320mm

Depth

235mm

244mm

300mm

Weight (net): 2.65Kg

Weight (gross): 3.27Kg

Certification:

Power Supply

Connector

Quantity

Max. Length

Mainboard 20+4Pin

P4 12V 4Pin

P4/EPS 4+4Pin

P8 12V 8Pin

PCI-Express 6+2Pin

PCI-Express 6Pin

IDE 4Pin

S-ATA

Floppy

RPM sensor cable

Fan Control

Fan: 120mm

1 2

Certification: 2
