Errors excepted. No warranty for the correctness of the information State: 19.08.2013

Specifications

Motherboard

ITX

Drive Bays

Slot-In: max. 1*

3.5" internal: max. 2*

2.5" internal: max. 2*

Front Connectors

USB 2.0: 1

USB 3.0: 1

Microphone: 1

Headphone: 1

External Connectors

SATA data port: 1

4Pin Molex power connector: 1

Cooling System

4x 80x80x15mm

(laterally, as option)

Packing Units

Shipping Unit: 1 Piece

Packing Units: 6 Pieces

Guarantee and Warranty

Case 24 Months Warranty

Power Supply 24 Months Guarantee

Article Number

EAN-Code

88881176

4260133125247

Scope of Delivery

External 84 Watt Power Supply

DC-board max. 120W

Cable ties

Screw set

Rubber feet

(glueable)

Features

External 84W Power Supply

1 low profile PCI card possible

Optional Accessories

External 120W PSU

(Art. 88882103)

*1.) in use of only Slot-In, you are able to mount 1x 3.5" or 2.5"

*2.) in use of a Slot-In ODD without a PCI card, you are able to mount 2x 3.5" or 2x 2.5"

*3.) in use of a Slot-In ODD together with a PCI card, you are able to mount 1x 3.5" or 1x 2.5"

*4.) in use of no Slot-In ODD and no PCI card, you are able to mount 2x 3.5" or 2x 2.5"

Dimensions and Weight

Cage

Case

Package

Height

100mm

165mm

Width

245mm

280mm

Depth

236mm

285mm

Weight (net): 1.64Kg

Weight (gross): 2.43Kg

Certification:

DC/DC-Platine:

Anschluss

Anzahl

Max. Länge

Mainboard 20+4Pin

P4 12V 4Pin

IDE 4Pin

S-ATA

Floppy

DC Output

Output Voltage (V)

Max. Output Current (A)

+3.30 V

+3.30

10.0

+5.00 V

+5.00

10.0

+5.00 VSB

+5.00

2.0

+12.00 V

+12.00

4.5

-12.00 V

-12.00

0.15

1 2

Certification: 2
